FT 2267/5

Single-acting flow control valves available from 1/4" to 1" size - METRIC THREADS. Max. working pressure 320 Bar, adjustable oil flow rate from 0,8 to 200 Lt./min. (depending on the size)

Single-acting control
No pressure compensated flow control
METRIC threads
Stainless Steel AISI 316
METRIC Threads cartridge single-acting flow control valves

Product code composition

Choose the different options below to configure the most useful product code for your needs.

The code will be generated and sent automatically by clicking on "Submit a request".

FT 2267/5
Gasket

* (NBR - standard)
** (V - FPM - standard per valvole Inox)
E (EPDM)
N (NEOPRENE)
S (SILICONE)
V (FPM)

Handwheel

* (MA - standard - aluminium)
MP (ABS)
RA (Aluminium spoked)
** no knob

Sfiato

* (no bleed)
S (with bleed)

Versione Speciale
Submit a request

The request can be sent only upon completion of all the choice fields


Technical information

They control and, in case, shut-off the flow in one direction and allow the full free flow in the opposite direction. • Check valve calibrated at 0,35 bar
