FT 357/2

Double-acting flow control stackable valves Cetop5, available with controlled flow A-B-P-T or double A+B ports. Max. working pressure 320 Bar, oil flow rate up to 45 Lt./min.

Cetop 5 valves - NG10
Flow control
Double-acting control
Carbon steel
Double-acting flow control valves Cetop 5 - ADJUSTMENT HANDWHEEL

Product code composition

Choose the different options below to configure the most useful product code for your needs.

The code will be generated and sent automatically by clicking on "Submit a request".

FT 357/2
Size

03 ( Cetop 03 )
05 ( Cetop 05 )

Control

* METER IN ( standard )
H ( METER OUT )
** (double acting)

Gasket

* NBR ( standard )
V ( FPM )

Submit a request

The request can be sent only upon completion of all the choice fields


Technical information

Flow rate control valve, not compensated, for modular mounting with subplate surface according to ISO 4401-05. It permits a fine fluid regulation in two directions even with low flow rate. The version with handwheel for flow regulation allows its locking thanks to the the screw it is equipped with. Flow rate 45L/min.
