FT 376/4

Pressure reducing stackable valves Cetop3, pilot control, available with controlled flow on A-B-P ports. Max. working pressure 320 Bar

Cetop 3 valves - NG6
Pressure reducing
Pilot control
Carbon steel
Setting regulation field:
05=10-60 Bar | 10=30-160 Bar | 20=60-260 Bar
Pilot pressure reducing valves Cetop 3

Product code composition

Choose the different options below to configure the most useful product code for your needs.

The code will be generated and sent automatically by clicking on "Submit a request".

FT 376/4
Size

03 ( Cetop 03 )
05 ( Cetop 05 )

Gasket

* NBR ( standard )
V ( FPM )

Setting regulation field

05
10
20
30

Submit a request

The request can be sent only upon completion of all the choice fields


Technical information

These valves are CETOP 03 reducing pressure in plate modular execution, ISO 4401 for superimposable mountings. Their function is to protect the secondary circuit from over pressure as they allow an inverted flow rate from the use to discharge T.
